Thermal Insulation Water Tank

The core working principle of the thermal insulation water tank is multi-layer composite thermal insulation technology. Through the three-layer composite structure of inner tank, insulation layer and outer protective layer, it specifically blocks three heat transfer paths: heat conduction, heat convection and heat radiation, realizing long-term constant temperature insulation of the water storage medium and minimizing heat loss during water storage. The inner tank, as the water storage carrier, adopts corrosion-resistant, food-grade metal material to realize sealed pressure water storage; the middle insulation layer uses high-density insulation material with low thermal conductivity to block the heat conduction path between the inner tank and the outside; the outer protective layer adopts high-strength protective material to isolate air convection and external environmental erosion, while protecting the internal insulation structure from external force damage. This technology complies with the relevant specifications of Standard for Design of Building Water Supply and Drainage GB 50015-2019, and also meets the mandatory requirements of Safety Evaluation Standard for Drinking Water Transmission and Distribution Equipment and Protective Materials GB/T 17219-1998 issued by the State Administration for Market Regulation of China, and fully conforms to the industry technical standards for water supply and drainage equipment issued by the Water Quality Association (WQA). It is an indispensable core supporting equipment in boiler hot water systems, HVAC water supply and industrial heat storage projects.

1. AIX Boiler: Factory Direct Strength and Core Brand Advantages

AIX Boiler is a national high-tech factory direct manufacturer integrating R&D, production, sales, installation and after-sales operation and maintenance of thermal insulation water tanks. It has a 15,000 ㎡ standardized production workshop, fully automatic CNC rolling and welding equipment, polyurethane high-pressure foaming production line and a professional R&D team of pressure vessels and thermal engineering. We have been deeply engaged in boiler supporting water treatment and heat storage equipment for more than ten years, focusing on customizing highly adaptable thermal insulation water tank solutions for various boiler systems, hot water projects and HVAC water supply scenarios. As an original factory direct supply enterprise, we eliminate all intermediate links. All core raw materials of the products are genuine products from first-tier brands, supporting full-process non-standard customization. From volume specification, material selection, insulation structure, pressure rating to interface layout, we can carry out exclusive design according to the user's boiler parameters, water demand, on-site working conditions and heat storage requirements. It can be perfectly adapted to our full series of boiler equipment and water treatment systems. At the same time, we provide a full chain of services including equipment installation, system linkage commissioning, operation training and lifelong after-sales maintenance, and have provided stable and reliable thermal insulation water tanks and boiler system supporting services for more than 6000 industrial enterprises, commercial complexes, hotels and hospitals, and municipal heating units nationwide.

Our product system covers the full series of thermal insulation water storage equipment. The core products include five core series: AIX boiler special thermal insulation hot water storage tank, food grade 304 stainless steel thermal insulation water tank, pressure insulated water tank, large horizontal/vertical thermal insulation water tank, and polyurethane foaming thermal insulation water tank, which can adapt to the full volume range of 0.5m³-2000m³. Whether it is small civil hot water boiler, commercial heating boiler supporting water storage, or large industrial steam boiler hot water recovery, central heating system heat storage, boiler feed water insulation storage scenarios, we can provide a 100% matching thermal insulation water storage solution to fully ensure the long-term efficient, stable and low-consumption operation of the boiler system.

2. Core Product Series and Technical Parameters of AIX Boiler Thermal Insulation Water Tank

As a factory direct manufacturer, we can provide customization services for all models and specifications of thermal insulation water tanks. The technical parameters of the core standard model products are shown in the table below. All parameters can be adjusted and optimized according to the user's actual boiler supporting demand and on-site working conditions:

3. Core Structure and Thermal Insulation Performance Design of AIX Boiler Insulated Water Tank

AIX boiler thermal insulation water tank is specially optimized for high temperature resistance, corrosion resistance, long service life and low heat loss for boiler operation scenarios. It adopts three-layer integrated composite structure design. The core structure includes three core main bodies: food grade pressure inner tank layer, high density thermal insulation layer, high strength outer protective layer, and five functional modules: water inlet and outlet interface, temperature control unit, liquid level monitoring unit, sewage discharge and exhaust unit, manhole maintenance unit. It can realize seamless docking and linkage control with our boiler system and water treatment system. The core structure design is as follows:

1. Food Grade Pressure Inner Tank Layer

As the core water storage carrier of the water tank, the inner tank is made of food grade 304/316L stainless steel, carbon steel rubber lined and other corrosion-resistant materials. It is integrally formed by fully automatic CNC rolling and welding process. The weld seam adopts argon arc welding double-sided forming technology, and passes 24-hour water pressure air tightness test, no leakage and no deformation. The inner wall is mirror polished, which is not easy to scale and breed microorganisms, and can be adapted to the storage of various media such as boiler feed water, domestic hot water, food processing water. It is specially designed for high temperature resistance for boiler high temperature hot water scenarios, and can withstand long-term storage of high temperature media up to 95℃, with a service life of more than 20 years.

2. High Density Thermal Insulation Layer

The insulation layer adopts high-density polyurethane rigid foam material formed by high-pressure integral foaming process, with density ≥38kg/m³, thermal conductivity ≤0.024W/(m·K), and thickness customized from 50mm to 200mm according to the application scenario, no joints and no hollowing, stable thermal insulation performance. For large industrial high-temperature heat storage scenarios, multi-layer composite insulation structure of polyurethane foaming + rock wool + vacuum insulation panel is adopted to further block heat radiation and heat conduction, achieving ultra-long-term insulation effect with 24h temperature drop ≤1.5℃, minimizing the heat loss during the storage of boiler hot water and reducing the energy consumption of repeated heating of the boiler.

3. High Strength Outer Protective Layer

The outer protective layer is made of high-strength protective materials such as 201/304 stainless steel, color steel plate, carbon steel plastic sprayed, with customized thickness from 0.8mm to 2.0mm. The surface is treated with anti-corrosion and anti-rust treatment, with flat and beautiful appearance, impact resistance, aging resistance and corrosion resistance. It can adapt to various installation environments such as indoor, outdoor and open air, effectively isolate external air convection and rain erosion, protect the internal insulation structure from damage, and can customize the appearance color and logo according to user needs, perfectly integrating with the site environment.

4. Exclusive Supporting Functional Units for Boiler Systems

For boiler supporting scenarios, the water tank can be customized with exclusive water inlet and outlet layout, seamlessly docking with the boiler hot water outlet, water return port and feed water system. It is equipped with intelligent temperature controller, liquid level sensor and pressure transmitter, which can be linked with the boiler PLC control system to monitor the water temperature, liquid level and pressure of the water tank in real time, automatically control the boiler water replenishment and heating start and stop without manual intervention, realizing fully automatic operation of the boiler system. At the same time, it is equipped with manhole, ladder, sewage outlet, exhaust valve, overflow port, sampling port and other accessories to facilitate daily maintenance, overhaul and water quality testing.

4. Core Competitive Advantages of AIX Boiler Insulated Water Tank

• Factory Direct Supply, Exclusive Customization for Boiler Systems: We have our own production workshop and fully automatic production line, no intermediate price difference. All products can be customized 1:1 according to the user's boiler model, system parameters, on-site working conditions. The interface layout, pressure rating, insulation structure and control logic are all optimized for boiler operation scenarios, and can be perfectly adapted to our full series of boilers and water treatment equipment, realizing one-stop procurement, installation and commissioning of the whole system, greatly reducing the user's procurement and communication costs.

• Food Grade Genuine Materials, Strict Production Quality Control: The inner tank raw materials all adopt genuine food grade stainless steel plates from first-tier brands such as TISCO and Baosteel, and the insulation layer adopts pure polyurethane fluorine-free foaming material. All raw materials have material inspection reports and food grade safety certifications. The production process strictly implements the ISO9001 quality management system. Each water tank has passed the water pressure test, air tightness test and temperature drop test before leaving the factory to ensure that the product meets the standard when leaving the factory and fully complies with the national drinking water safety related specifications.

• Ultra-long-term Thermal Insulation Performance, Extreme Energy Saving and Consumption Reduction: Adopting high-pressure integral foaming process and multi-layer composite insulation structure, the insulation layer has no hollowing and no joints, with extremely low thermal conductivity. The 24h temperature drop can be controlled within 1.5℃ at the lowest, far exceeding the industry average level. It can minimize the heat loss during the storage of boiler hot water, avoid frequent start and stop heating of the boiler, and reduce the boiler operation energy consumption by 15%-20% under the same working conditions, greatly saving the user's long-term operation cost.

• Precision Welding Technology, Durable Corrosion Resistance and Long Service Life: Adopting fully automatic CNC welding equipment and argon arc welding double-sided forming technology, the weld seam is flat and uniform, no false welding and no missing welding. The inner wall of the inner tank is passivated and polished, which is not easy to scale and corrode. For high hardness water quality and corrosive medium scenarios, 316L stainless steel and carbon steel rubber lined inner tanks can be customized. The normal service life can reach more than 20 years, greatly reducing the equipment replacement and maintenance costs.

• Full Chain After-sales Service, Lifelong Operation and Maintenance Guarantee: We have a professional installation and after-sales operation and maintenance team, which can provide full-process services of factory prefabricated delivery, on-site assembly and welding, system linkage commissioning nationwide. After the equipment is delivered, we provide 24 months free warranty, lifelong supply of original factory parts, technical upgrade and on-site maintenance services, 7*24 hours technical response, to ensure the long-term stable operation of the user's equipment.

5. AIX Boiler Full Process Insulated Water Tank Solution Service System

As a professional factory direct manufacturer of boilers and heat storage equipment, we not only provide high-quality insulated water tank products, but also provide users with a full-process, one-stop boiler supporting heat storage solution, covering the whole project cycle:

1. Pre-site Survey and Scheme Design: We provide free on-site survey, heat load calculation and system adaptation design services for users. Professional thermal engineers tailor the exclusive insulated water tank solution according to the boiler parameters, water demand, on-site working conditions and installation environment, and issue a detailed product parameter list, installation layout drawing, interface docking drawing and cost calculation.

2. Original Factory Production and Whole Process Quality Control: All products are produced and processed in our own factory, and the whole process testing is carried out in strict accordance with the ISO9001 quality management system. From raw material incoming inspection, production process welding quality control, foaming molding inspection, to factory water pressure test, air tightness test, temperature drop test, each link has strict quality control to ensure that the products meet the design requirements and relevant national standards.

3. Professional Installation and System Linkage Commissioning: The professional installation team provides on-site installation services, small finished water tanks are positioned and docked on site, and large water tanks are assembled and welded on site. The whole process strictly implements the construction specifications. After the installation is completed, the linkage commissioning with the boiler system and water treatment system is carried out to ensure that the water temperature, liquid level and pressure control are perfectly linked with the boiler system, and the equipment is delivered to users after the operating status meets the standards.

4. Operation Training and Technical Disclosure: Provide one-to-one full process training on daily equipment operation, maintenance and fault troubleshooting for user operators, issue detailed product operation manual, maintenance guide and safety operation procedures to ensure that users can independently complete the daily operation and maintenance of the equipment.

5. Lifelong After-sales and Operation Maintenance Guarantee: After the equipment is delivered, we provide free warranty service, lifelong supply of original factory parts, technical upgrading and on-site operation and maintenance services, regularly return visit the equipment operation status, provide users with preventive maintenance suggestions, and fully solve the user's worries.

6. Relevant Industry Standards and Specifications for Insulated Water Tanks

The production, installation and acceptance of all AIX boiler insulated water tanks are strictly in accordance with the current relevant national standards and specifications. The core implementation standards include:

• Standard for Design of Building Water Supply and Drainage GB 50015-2019

• Safety Evaluation Standard for Drinking Water Transmission and Distribution Equipment and Protective Materials GB/T 17219-1998

• Code for Construction of Field Equipment and Industrial Pipeline Welding Engineering GB 50236-2011

• Non-destructive Testing of Pressure Equipment JB/T 4730-2015

• Code for Design of Insulation Engineering of Industrial Equipment and Pipelines GB 50264-2013

• Hygienic Specification for Secondary Water Supply Facilities GB 17051-1997

Our products have fully passed the testing of third-party authoritative institutions. The material safety, thermal insulation performance, welding quality and pressure performance fully meet the requirements of relevant national standards, which can meet the needs of annual inspection, environmental assessment and sanitary acceptance of various boiler systems, and also adapt to the compliant use requirements of civil, commercial, industrial and other scenarios.
