Enamel Disc Heat Exchanger

Enamel disc Heat Exchanger operates based on three core principles: counter-current heat exchange, turbulent enhanced heat transfer, and high-efficiency heat conduction through disc interlayers. It consists of multiple stacked enamel discs forming independent cold and hot flow channels. High-temperature medium flows along disc gaps, cooling water flows reversely in disc interlayers, achieving efficient heat exchange through dense high-silicon enamel layer to complete cooling, condensation and waste heat recovery. With Q245R carbon steel as base material and high-temperature sintered enamel layer, it combines metal strength and glass-grade corrosion resistance. As a core heat exchange equipment for highly corrosive working conditions certified by China Standardization Administration, AIX Boiler, as an original factory, strictly follows Standardization Administration of China standards HG/T2056-2018, GB150, TSG21-2016, independently controlling design, manufacturing and testing to ensure safe, compliant, stable and durable products.

1. AIX Boiler Brand & Original Factory Core Advantages

AIX Boiler is a comprehensive chemical equipment manufacturer integrating R&D, design, production, installation, commissioning and EPC service, specializing in enamel disc heat exchangers, shell and tube heat exchangers, spiral plate heat exchangers, storage tanks, pressure vessels and other equipment. We have intelligent workshops, professional enamel sintering and NDT teams, complete forming and pressure testing equipment, realizing independent production from plate procurement and re-inspection, CNC cutting, stamping, enamel sintering, assembly, sealing test, hydrostatic test to finished product delivery without middlemen, providing higher cost performance and more controllable delivery time with the same quality. With years of deep cultivation in heat exchange equipment industry, our products have passed many authoritative tests, complying with Class I pressure vessel safety standards, adapting to strict working conditions in chemical, petroleum, pharmaceutical, dyestuff, metallurgy and other industries, serving thousands of enterprises nationwide, winning market trust with stable quality, professional technology and perfect service, becoming a trustworthy brand manufacturer in enamel disc heat exchanger field.

2. Working Principle & Structural Features

Enamel disc heat exchanger adopts stacked disc structure, composed of upper cover, lower cover, enamel discs, PTFE-coated gaskets and fasteners, with cold and hot media completely isolated without cross-contamination. New six-hole design ensures uniform fluid distribution, reduces single disc thickness to improve cooling water flow rate, heat transfer efficiency increased by more than 50% compared with standard type; 10mm thick gasket has small expansion and contraction, high pressure resistance, suitable for high vacuum sealing; smooth disc surface is not easy to scale, easy to maintain; modular disc design can flexibly adjust heat exchange area by adding or reducing discs, local replacement available for damage, greatly reducing use cost. AIX products resist acid, alkali and organic solvents, with wide temperature range, suitable for heat exchange and condensation of most non-toxic, non-explosive, highly corrosive media.

3. Core Technical Parameters & Standards

4. Standard Model Parameter Table

5. Manufacturing Process & Quality Control

AIX Boiler implements full-process strict quality control for enamel disc heat exchangers: 1) Material control: selecting high-quality Q245R steel plates with material certificates and re-inspection reports; 2) Precision forming: CNC stamping discs with high dimensional accuracy and uniform stress; 3) Enamel sintering: high-silicon corrosion-resistant enamel sintered at 900℃ for dense, uniform, pinhole-free layer, withstand voltage ≥20KV; 4) Sealing assembly: PTFE-coated gaskets + symmetrical fastening for reliable high-vacuum sealing; 5) NDT: 20% X-ray inspection for Class A & B welds, kerosene leak test qualified, surface NDT Level I for key welds; 6) Pressure test: hydrostatic test per GB/T7994, air tightness test customizable; 7) Surface treatment: coating per GB25025-2010 for rust prevention and aesthetics. Each equipment provides complete delivery documents to meet safety and environmental acceptance requirements.

6. Application Industries & Scenarios

AIX enamel disc heat exchangers are widely used:
1. Chemical: heat exchange and condensation of organic acid, inorganic acid, ester, alcohol, solvent and other highly corrosive media;
2. Pharmaceutical: API, intermediate, solvent recovery, distillation and rectification system condensation;
3. Dyestuff & Pigment: steam condensation and heat recovery of various dyes, pigments and intermediates;
4. Fine Chemical: spice, additive, volatile and corrosive material cooling;
5. Petrochemical: oil refining, oil & gas recovery, tail gas condensation treatment;
6. Others: pesticide, coating, environmental waste liquid treatment, high vacuum system condensation.

7. OEM Customization & One-stop Service

As an original factory, AIX Boiler provides full-range customization: professional design according to medium characteristics, temperature, pressure, flow, heat exchange area, installation space; support P0.5, P1, P2 standard and non-standard customization; optional flange, cooling pipe, pressure gauge port, drain port; one-stop on-site installation, commissioning, acceptance, training and after-sales maintenance, undertaking EPC general contracting of heat exchange system to reduce customer cost and project risk.

8. Core Competitiveness & Advantages

Compared with traditional shell and tube, sleeve heat exchangers, AIX enamel disc heat exchangers have outstanding advantages: 1) Stronger corrosion resistance, suitable for highly corrosive media, service life much longer than ordinary carbon steel equipment; 2) Higher heat transfer efficiency, 50%+ improvement with six-hole design + counter-current turbulence; 3) More compact structure, small size, light weight, less space; 4) Excellent high vacuum sealing performance with 10mm thick gasket; 5) Not easy to scale, easy to maintain, modular design for local replacement; 6) Original factory direct supply with controllable quality, stable delivery and fast after-sales; 7) Compliant with Class I pressure vessel standards, complete qualifications and testing, smoothly passing various inspections.

9. Purchase & Cooperation Process

For purchasing enamel disc heat exchangers, please provide: medium name, temperature, pressure, flow, required heat exchange area, material requirement, installation type, site conditions, interface specification. Our engineers provide scheme and quotation one-to-one. AIX Boiler adheres to quality first and integrity management. All products are delivered after strict testing, providing long-term technical support and spare parts supply. Welcome to visit our factory and discuss cooperation.

AIX Boiler – Professional Original Factory of Enamel Disc Heat Exchangers, Building Quality with Technology, Winning Trust with Service, Providing Safe, High-Efficiency, Corrosion-Resistant Heat Exchange Equipment and Total Solutions for Global Customers.
